- Description
-
Details
Chamber Type / Size T20 Service Chamber Joint Type Single Clamp Band Stud Thread Size M16 x 1.5-6g Mounting Stud Length 1.70 IN (43.2 MM) Stud Spacing 4.75 IN (120.7 MM) Stroke 2.50 IN (63.5 MM) Push Rod Thread / Style Spherical End Push Rod Length [MM] 15. mm Service Port (11) 3/8-18 NPTF Port Angle All Open Clamp Angle Universal Service Chamber Vent Holes Universal Maximum Operating Temperature 176 °F (80 °C) Minimum Operating Temperature -40 °F (-40 °C) - Additional Information
-
Additional Information
SKU DS20EMBR15 Cross Reference SC20D, K028225 Remarks Gross Weight 3.615 Net Weight 3.615 Minimum Order Quantity (MOQ) Depends on the price. Incoterms (Int'l Comm. Terms) T/T when pick up the goods. Suggested Retail Price No
